Grandstream GWN7801 Enterprise Layer 2+ Managed Network Switch with 8 x 1GigE, 2 x SFP Ports
The Grandstream GWN7801 is an 8-port Gigabit Layer 2+ managed switch with 2 Gigabit SFP ports, delivering a 20 Gbps switching capacity and 14.88 Mpps forwarding rate. It supports IPv4/IPv6, QoS, and offers advanced security features like port security, DHCP snooping, and DoS protection. With a built-in 30W power supply and flexible management via GWN.Cloud, GWN Manager, or local Web UI, it's ideal for businesses needing reliable, secure, and high-performance networking.
- AVAILABILITY: Pre Order
- PRODUCT CODE: NA
- CATEGORY: Networking
1 Gigabit Ethernet
8 / 10 - Ports
Manageable
SFP Ports / Combo Ports
Layer 2
Technical Specifications
Manufacturer's code | GWN7801 |
| Network Protocol | IPv4, IPv6, IEEE 802.3, IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3x, IEEE 802.3af/at, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1d, IEEE 802.1s |
| Gigabit Ethernet Ports | 8 |
| Gigabit SFP Ports | 2 |
| Console | 1 |
| # of PoE Ports | None |
| Integrated Power Supply | 30W |
| Max Output Power per PoE Port | None |
| Max Total PoE Output Power | None |
| PoE Standards | None |
| Auxiliary Ports | 1x Reset Pinhole |
| Forwarding Mode | Store-and-forward |
| Total non-blocking throughput | 10Gbps |
| Switching Capability | 20Gbps |
| Forwarding Rate | 14.88M packets per second |
| Packet Buffer | 4.1MB |
| Switching | 8K static, dynamic and filtering MAC addresses; 4K VLANs, port-based VLAN, IEEE 802.1Q VLAN tagging, voice VLAN; VLAN virtual interface; GVRP (pending); 8 link aggregation groups; Spanning tree, 64 instances for STP/RTSP/MSTP |
| Multicast | IGMP Snooping, MLD Snooping, MVR |
| QoS/ACL | Auto detection and prioritization of voice/video/RTP/SIP/other latency-sensitive packets (pending); Port priority; Priority mapping; Queue scheduling, including SP, WRR, WFQ, SP-WRR and SP-WFQ; Traffic shaping; Rate limit; 1.5K ACL for Ethernet, IPv4 and IPv6 |
| DHCP | DHCP server, DHCP relay, Option 82, 60,160 and 43 |
| Maintenance | CPU and memory monitoring, SNMP, RMON, LLDP&LLDP-MED, backup and restore, syslog, alert, diagnostics including Ping, Traceroute, port mirroring, UDLD(TBD) and copper test |
| Security | User hierarchical management and password protection, HTTPS, SSH, Telnet; 802.1X authentication; AAA authentication including RADIUS, TACACS+; Storm control; Port isolation, port security, sticky MAC; Filtering MAC address; IP source guard, DoS attack prevention, ARP inspection; DHCP Snooping; Loop protection including BPDU protection, root protection and loopback protection; Kensington Security Slot (Kensington Lock) support |
| Mounting | Desktop/Wall-Mount |
| LEDs | 1x tri-color LED for device tracking and status indication, 10x green LEDs for data ports |
| Fan | None |
| Environmental | Operation: 0°Cto 45°C, humidity 10-90% RH(Non-condensing) |
| Dimensions | 330mm(L)*175mm(W)*44(H) |
-
Data SheetDownload
