MERCUSYS MS108G 8-Port 10/100/1,000 Mbps Desktop Switch
This 8-Port Gigabit Switch features auto-negotiation RJ45
ports with MDI/MDIX support for effortless wired network expansion. Its compact
design allows flexible placement, while the plug-and-play setup requires no
configuration. Green Ethernet technology helps reduce power consumption by up
to 82%, making it both efficient and eco-friendly.
- AVAILABILITY: In Stock
- PRODUCT CODE: 100-10206
- CATEGORY: Networking
1 Gigabit Ethernet
8 / 10 - Ports
Unmanageable
Non PoE
Technical Specifications
- Hardware
- Standards and Protocols
IEEE 802.3, IEEE 802.3u, IEEE 802.3x CSMA/CD
- Dimensions 127 x 60.3 x 22 mm
- Interfaces
8 10/100/1000Mbps Ports, Auto-Negotiation,
Auto-MDI/MDIX- External Power Supply 9V/0.6A
- Data Rates
10/100/1000Mbps at Half Duplex
20/200/2000Mbps at Full Duplex- Buffer Capacity 64KB
- Jumbo Frame
16 KB
- LED Ethernet (1, 2, 3, 4, 5, 6, 7, 8), Power
- Software
- Transfer Method
Store and Forward
- Others
- Package Contents
• 8-Port 10/100/1000Mbps Desktop Switch (MS108G)
• Power Adapter
• Quick Installation Guide
-
Data SheetDownload
